Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line
  • Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line
  • Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line
  • Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line
  • Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line
  • Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line
  • Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line

Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line

Herkunftsort Shanghai
Markenname Gofun
Zertifizierung CE, ISO certificate
Modellnummer GFM-MPL
Einzelheiten zum Produkt
Garantie:
12 Monate
Zertifizierung:
CE/ ISO9001
Stromspannung:
220/380/440V nach Angaben der Kunden
Leistung(w):
7,5 kW
Typ:
Schlüsselfertige Verarbeitungslinie von a bis z
Material:
SUS304/ SUS316
Kapazität:
1 T/H-20 T/H
Produktname:
Mango getrocknete Verarbeitungsmaschine
Kundendienst:
Technischer Unterstützung in Übersee
Anwendung:
Mango
Zustand:
Neu
Gewicht:
individuell angepasst
Hervorheben:

commercial mango drying machine line

,

mango chip processing equipment

,

sliced dried mango production line

Zahlungs- und Versandbedingungen
Min Bestellmenge
1 Satz
Preis
negotiable
Verpackung Informationen
Internationales Standardpaket für den Versand
Lieferzeit
45 ~ 90 Tage
Zahlungsbedingungen
T/T, Western Union, L/C
Versorgungsmaterial-Fähigkeit
100 Sätze pro Jahr
Beschreibung des Produkts
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line

Global mango processing plants are increasingly turning to automated production machinery to achieve unmatched efficiency, product consistency, and long-term cost savings. Our purpose-built dried mango processing machine is meticulously engineered to meet the rigorous demands of professional mango processing operations—whether for small-batch artisanal production or large-scale industrial manufacturing.

At the heart of our offering is the integrated Dried Mango Production System, a versatile dried mango processing machine designed to streamline the entire workflow from fresh fruit to finished dried product. This system seamlessly combines critical stages including mango washing, peeling, slicing, color protection, sugar infusion, drying, and cooling—all within a single automated dried mango processing machine. By replacing manual handling, it eliminates operational inefficiencies and ensures uniform moisture content, consistent texture, and standardized sweetness batch after batch.

Tailored for mango processing plants focused on scalability and labor reduction, our dried mango processing machine features adjustable temperature and drying time settings to accommodate different mango varieties and final product requirements. Every component of this dried mango processing machine is designed for easy cleaning and full compliance with international food hygiene standards, ensuring both operational efficiency and hassle-free maintenance.

Backed by reliable after-sales support, our automated dried mango processing machine delivers long-term operational stability, increasing production output by up to 80% while significantly minimizing material waste. From raw fruit intake to finished dried mango slices, this integrated dried mango processing machine offers mango processors a strategic investment path toward greater competitiveness, efficiency, and market growth.

Technical Specifications
Product Name One-stop solution for mango processing line
Fresh Fruit Inlet Capacity 500kg per hour ~ 25 tons per hour, customized
Raw Material Fresh mango
End Products Mango pulp puree, Mango concentrate, Mango sauce, Mango juice, Mango beverage
Final Product Brix 14%~20%
Final Package Options Aseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc
Machine Material Food grade SUS304 or SUS316
Warranty 12 months after commissioning
Operator Requirement About 10~12 persons
Voltage 380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard)
Advantages Energy-saving, High efficiency, Water-saving, Stable performance
Processing Flowchart
FRESH MANGO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ DESTINING ⇒ PREHEATING ⇒ PULPING & REFINING ⇒ CENTRIFUGE ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 0
Final Products & Packaging Options
Our processing line utilizes fresh mango and mango paste as raw materials to produce various final products including mango paste, mango sauce, mango juice, mango powder, diced mango, and dried mango.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 1
Available packaging formats include aseptic bags, metal cans, sachets, stand-up pouches, PP containers, glass bottles, PET bottles, and gable top cartons.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 2
Key Features
  • Full-process Integration: Comprehensive mango processing from pretreatment to bottling of finished products within a single integrated system
  • Safety Assurance: Built with 304/316 stainless steel and FDA/CE certification for ensuring food safety standards
  • Smart and Productive: Precise parameter control via PLC with adjustable capacity ranging from 500kg/h to 10t/h
  • Energy-efficient and Eco-friendly: Low-power configuration to minimize operational expenses
  • Versatile Functionality: Capable of processing mango pulp, various juices, and vegetable purees
  • Complete Support: Tailored design, installation, commissioning, technical training, and post-sales assistance services
Detailed Process Steps
1. Discharge Platform
Specialized drainage platform with water guns simplifies raw mango unloading from trucks while providing pre-washing capabilities to enhance production line efficiency.
2. Elevator
This machine transports fresh mango from outside the building to inside the processing facility.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 3
3. Washing
Thorough washing of fresh fruits prior to crushing using bubble washers and brush & spray washers. Optional ultrasonic and ozone cleaning methods available for enhanced cleaning efficacy.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 4
4. Sorting
Visual inspection by staff after washing to identify defects, ensuring only high-quality fruits proceed through the production line.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 5
5. Destoning
Mango remover operates at 1470 r/min, effectively crushing fresh mango to ensure thorough cleaning of core and skin, maximizing pulp yield and production efficiency.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 6
6. Preheating
Adjustable temperature pre-heater (45℃ to 85℃) increases juice yield for subsequent processing while protecting final product color and taste.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 7
7. Pulper and Refiner
Operating at 1470 r/min, this machine generates centrifugal force to pass product through screens for refinement. Suitable for various fruits including passion fruit, tomatoes, peaches, apricots, mangoes, and apples.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 8
8. Horizontal Spiral Centrifugal
Reduces solids and impurities to ensure mango pulp puree is free from contaminants and black spots.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 9
9. Sterilizing
Tube-in-tube type sterilizer with adjustable temperature and retention time for different product requirements. Programmable control system ensures precise automation.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 10
10. Aseptic Filling
Operates with tube-in-tube sterilizer in closed cycle system. Vapor-protected filling cavity maintains sterility throughout the packaging process.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 11
11. Storage or Blending
Final product can be stored as-is or used as raw material for producing mango sauce or other products.
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 12
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 13
Commercial Mango Dried Fruit Processing Line | Complete Mango Chip & Sliced Dried Machine Line 14
